320 Sundancer Canvas Scoll Down for Years and Pricing
Quote Request Form & Colors at Bottom of Page
This website offers detailed information on the replacement canvas options for 320 Sundancers, model years 2002-2007. We offer all the same canvas that was available with the boat when it was new.
We offer the Original Equipment from patterns made when the boats were new. The canvas has the same zipper placements, so the parts are interchangeable with other factory original Sea Ray canvas and frames.
Our specialty is canvas specifically for Sundancers. We also offer installation tools and detailed instructions, shown in our how-to videos. Contact us for a quote for new canvas for your 320 Sundancer today!
2005 320DA with Captain Navy Canvas
Available Parts
Bimini & Sunshade Tops
Sunbrella canvas for the Tops, Seamark has been discontinued. Tops have zippers in factory original locations to connect to front, side and aft windows. Bimini and Sunshade zipper valances slide into the tracks on the arch and connect to the tops and side windows.
Windows
Factory original windows: Front 3 windows, 2 side windows and aft enclosure curtain. Zippers positioned to match up to original tops and connect to windshield frame, gunnels and transom with snaps, extrusion, or Stay Put Bungees, depending on model year.
Cockpit Cover
Sunbrella canvas with support poles and snap fastener kit. Cutouts to fit around bimini frame mounts, if equipped.
Frames for Canvas Tops
Stainless steel frames for Bimini and Sunshade Tops. No Camper frames are available.
Canvas Accessories
Bimini and Sunshade top storage boots, helm covers and snap in carpet runners for the cabin are available depending on the model year.
No Camper Packages for the 320
Sea Ray didn't offer any camper packages on Sundnacers over 30 feet. You'd need to get this custom made locally to fit your boat.
2002 320 Sundancer
2002 was the first year of this hull for the 320 Sundancer
Available Canvas for 2002 320 Sundancer:
Bimini Top (forward of arch, fabric portion, no frame) $1,127
Bimini Top Zipper Valance (slides into C track on Arch) $252
Visor (3 front windows) $838
Bimini Side Curtains (2 side windows) $658
Aft Sunshade top (behind arch, fabric portion no frame) $1,231
Aft Zipper Valance (Slides into C track on Arch) $275
SS Aft Enclosure Curtains (rear sloping canvas with window) $1,262
10 piece Slope Back Enclosure Package Price: $5,592
Cockpit cover with support poles and snaps $1,667
Cockpit Carpet for exterior deck, not in the cabin: 3 piece set, with hole for table stanchion in tan or grey berber with upgraded vinyl backing that doesn't flake off. $878 + shipping. Snaps included and pressed into carpet at the boat, loaner tool available.
The original colors of Sunbrella canvas used in 2002 on the 320 Sundancer were: Black, Toast Tweed, Mediterranean Blue Tweed and Forest Green. See color card at bottom of webpage. Your canvas can be made in any of the colors shown. The 3 red options are premium colors and the canvas is about 15% more.
No camper packages for the 320 Sundancers.
Typically the stainless steel frames for the tops are reused. We can offer frames if you need them. Message us a quote on the frames.
2002 320 Sundancer, Full enclosure without the Sunshade aft curtain in Black Sunbrella Canvas.
2003 320 Sundancer
Available Canvas for 2003 320 Sundancer:
Bimini Top (forward of arch, fabric portion, no frame) $1,137
Bimini Top Zipper Valance (slides into C track on Arch) $238
Visor (3 front windows) $838
Bimini Side Curtains (2 side windows) $658
Aft Sunshade top (behind arch, fabric portion no frame) $1,231
Aft Zipper Valance (Slides into C track on Arch) $308
SS Aft Enclosure Curtains (rear sloping canvas with window) $1,262
10 piece Slope Back Enclosure Package Price: $5,592
Cockpit cover with support poles and snaps $1,834
Cockpit Carpet for exterior deck, not in the cabin: 3 piece set, with hole for table stanchion in tan or grey berber with upgraded vinyl backing that doesn't flake off. $878 + shipping. Snaps included and pressed into carpet at the boat, loaner tool available.
The original colors of Sunbrella canvas used in 2003 on the 320 Sundancer were: Black, Toast Tweed, Mediterranean Blue Tweed and Forest Green. See color card at bottom of webpage. Your canvas can be made in any of the colors shown. The 3 red options are premium colors and the canvas is about 15% more.
No camper packages for the 320 Sundancers.
Typically the stainless steel frames for the tops are reused. We can offer frames if you need them. Message us a quote on the frames.
2003 320 Sundancer, Bimini and Sunshade tops in Med Blue Tweed Sunbrella Canvas.
2004 320 Sundancer
Available Canvas for 2004 320 Sundancer:
Bimini Top (forward of arch, fabric portion, no frame) $1,276
Bimini Top Zipper Valance (slides into C track on Arch) $236
Visor (3 front windows) $838
Bimini Side Curtains (2 side windows) $658
Aft Sunshade top (behind arch, fabric portion no frame) $1,329
Aft Zipper Valance (Slides into C track on Arch) $308
SS Aft Enclosure Curtains (rear sloping canvas with window) $1,453
10 piece Slope Back Enclosure Package Price: $5,982
Cockpit cover with support poles and snaps $1,971
Cockpit Carpet for exterior deck, not in the cabin: 3 piece set, with hole for table stanchion in tan or grey berber with upgraded vinyl backing that doesn't flake off. $878 + shipping. Snaps included and pressed into carpet at the boat, loaner tool available.
The original colors of Sunbrella canvas used in 2004 on the 320 Sundancer were: Black, Toast Tweed, Captain Navy and Forest Green. See color card at bottom of webpage. Your canvas can be made in any of the colors shown. The 3 red options are premium colors and the canvas is about 15% more.
No camper packages for the 320 Sundancers.
Typically the stainless steel frames for the tops are reused. We can offer frames if you need them. Message us a quote on the frames.
2004 320 Sundancer, Bimini and Sunshade tops, Cockpit cover in Captain Navy Sunbrella Canvas.
2005 320 Sundancer
First year Sea Ray used Aluminum and Stainless Steel for the Windshield Frames, Canvas is Different
Available Canvas for 2005 320 Sundancer:
Aluminum Windshield Frame:
Bimini Top (forward of arch, fabric portion, no frame) $1,276
Bimini Top Zipper Valance (slides into C track on Arch) $297
Visor (3 front windows) $875
Bimini Side Curtains (2 side windows) $694
Aft Sunshade top (behind arch, fabric portion no frame) $1,329
Aft Zipper Valance (Slides into C track on Arch) $308
SS Aft Enclosure Curtains (rear sloping canvas with window) $1,462
10 piece Slope Back Enclosure Package Price, Aluminum WS Frame: $6,048
Cockpit cover with support poles and snaps $1,971
Cockpit Carpet for exterior deck, not in the cabin: 3 piece set, with hole for table stanchion in tan or grey berber with upgraded vinyl backing that doesn't flake off. $878 + shipping. Snaps included and pressed into carpet at the boat, loaner tool available.
Stainless Steel Windshield Frame:
Bimini Top (forward of arch, fabric portion, no frame) $1,276
Bimini Top Zipper Valance (slides into C track on Arch) $297
Visor (3 front windows) $858
Bimini Side Curtains (2 side windows) $681
Aft Sunshade top (behind arch, fabric portion no frame) $1,329
Aft Zipper Valance (Slides into C track on Arch) $308
SS Aft Enclosure Curtains (rear sloping canvas with window) $1,462
10 piece Slope Back Enclosure Package Price, Stainless WS Frame: $6,023
Cockpit cover with support poles and snaps $1,971
Cockpit Carpet for exterior deck, not in the cabin: 3 piece set, with hole for table stanchion in tan or grey berber with upgraded vinyl backing that doesn't flake off. $878 + shipping. Snaps included and pressed into carpet at the boat, loaner tool available.
The original colors of Sunbrella canvas used in 2005 on the 320 Sundancer were: Black, Toast Tweed, Captain Navy and Forest Green. See color card at bottom of webpage. Your canvas can be made in any of the colors shown. The 3 red options are premium colors and the canvas is about 15% more.
No camper packages for the 320 Sundancers.
Typically the stainless steel frames for the tops are reused. We can offer frames if you need them. Message us a quote on the frames.
2005 320 Sundancer, Aluminum vs Stainless Steel Windshield Frame.
2006 320 Sundancer
First Year for Standard Tops or Lace on Tops. Lace on Tops Have the Thicker Frame, Bolted to Arch
Available Canvas for 2006 320 Sundancer:
Standard Tops:
Bimini Top (forward of arch, fabric portion, no frame) $1,228
Bimini Top Zipper Valance (slides into C track on Arch) $305
Visor (3 front windows) $875
Bimini Side Curtains (2 side windows) $694
Aft Sunshade top (behind arch, fabric portion no frame) $1,384
Aft Zipper Valance (Slides into C track on Arch) $314
SS Aft Enclosure Curtains (rear sloping canvas with window) $1,482
10 Piece Slope Back Enclosure Package Price, Standard Tops: $6,194
Cockpit cover with support poles and snaps $2,012
Lace on Tops:
Bimini Top (forward of arch, fabric portion, no frame) $965
No Zipper Valances on this Version
Visor (3 front windows) $855
Bimini Side Curtains (2 side windows) $662
Aft Sunshade top (behind arch, fabric portion no frame) $864
SS Aft Enclosure Curtains (rear sloping canvas with window) $1,560
8 Piece Slope Back Enclosure Package Price, Lace on Tops: $4,752
Cockpit cover with support poles and snaps $1,785
Cockpit Carpet for exterior deck, not in the cabin: 3 piece set, with hole for table stanchion in tan or grey berber with upgraded vinyl backing that doesn't flake off. $878 + shipping. Snaps included and pressed into carpet at the boat, loaner tool available.
The original colors of Sunbrella canvas used in 2006 on the 320 Sundancer were: Black and Captain Navy. See color card at bottom of webpage. Your canvas can be made in any of the colors shown. The 3 red options are premium colors and the canvas is about 15% more.
No camper packages for the 320 Sundancers.
Typically the stainless steel frames for the tops are reused. We can offer frames if you need them. Message us a quote on the frames.
2006 320 Sundancer, With Lace on Tops, Visor (3 front windows) in Black Sunbrella.
2007 320 Sundancer
Standard Tops or Lace on Tops. Lace on Tops Have the Thicker Frame, Bolted to Arch
Available Canvas for 2007 320 Sundancer:
Standard Tops with Aluminum WS Frame:
Bimini Top (forward of arch, fabric portion, no frame) $1,228
Bimini Top Zipper Valance (slides into C track on Arch) $305
Visor (3 front windows) $875
Bimini Side Curtains (2 side windows) $694
Aft Sunshade top (behind arch, fabric portion no frame) $1,384
Aft Zipper Valance (Slides into C track on Arch) $314
SS Aft Enclosure Curtains (rear sloping canvas with window) $1,482
10 Piece Slope Back Enclosure Package Price, Standard Tops, Alum WS Frame: $6,194
Cockpit cover with support poles and snaps $2,012
Cockpit Carpet for exterior deck, not in the cabin: 3 piece set, with hole for table stanchion in tan or grey berber with upgraded vinyl backing that doesn't flake off. $878 + shipping. Snaps included and pressed into carpet at the boat, loaner tool available.
Lace on Tops, Aluminum or Stainless Steel WS Frame:
Bimini Top (forward of arch, fabric portion, no frame) $965
No Zipper Valances on this Version
Visor (3 front windows) $855
Bimini Side Curtains (2 side windows) $662
Aft Sunshade top (behind arch, fabric portion no frame) $864
SS Aft Enclosure Curtains (rear sloping canvas with window) $1,560
8 Piece Slope Back Enclosure Package Price, Lace on Tops SS WS Frame: $4,752
Cockpit cover with support poles and snaps $1,785
The original colors of Sunbrella canvas used in 2007 on the 320 Sundancer were: Black and Captain Navy. See color card at bottom of webpage. Your canvas can be made in any of the colors shown. The 3 red options are premium colors and the canvas is about 15% more.
No camper packages for the 320 Sundancers.
Typically the stainless steel frames for the tops are reused. We can offer frames if you need them. Message us for a quote on the frames.
2007 320 Sundancer, With Lace on Tops, Sunshade top and SS Aft Enclosure Curtains in Captain Navy.
Original Colors of Sunbrella Canvas used by Sea Ray
